Single serve capsules production systems

We have extended our technological range to the single-serve production sector, being able to transfer all the advantages of a complete and cutting-edge service: R&D capabilities, engineering and design experts, a worldwide after-sales support.

Output

  • multilayer technology up to 800 capsules/min
  • monomaterial technology up to 1600 capsules/min

CCMM - Continuous Compression Multilayer Moulding

The concept is to extrude a flat pellet of multilayer material and insert it into a standard compression mould (not applicable in the injection process).
A continuous work cycle is carried out, during which a flat multilayer pellet is cutted, placed into an open mould, formed into a capsule, ejected into a conveyor belt and real-time inspected.
The structure and positioning of the barrier layer wouldn’t change in the transition from pellet to molded part.

Download the catalogue

CCMM Continuous Compression Moulding Machine

TECNICAL DATA CCMM32A
RAW MATERIAL PP - HDPE - LDPE - PS - PET - PC - BIO
OUTER MAX Ø mm 60
MAX HEIGHT mm 45
NUMBER OF CAVITIES 32
MAX PROD.CAPACITY pcs/minute 800
ELECTRICAL POWER (UP TO) kw/kg 0,8
OVERALL DIMENSION mm 8700X2850
MIN CYCLE TIME s 2,4
SMART PACK AVAILABLE

CCMM Video

CCMM Video

INSPECTION SYSTEMS FOR CAPSULES

Making the invisible visible: this is the most demanding inspection carried out with our Computer Vision systems for plastic capsule, where it is necessary to check not only the product and public sides, but also the embedded barrier layer

Read more

INSPECTION SYSTEMS FOR CAPSULES

CCM Continuous Compression Moulding Machine

CCM hydraulic rotary presses are specially designed to produce thermoplastic products by means of compression.
A continuous work cycle is carried out, during which the plastic material is fed by a plasticization unit, cut into suitably sized pellets and then inserted inside the cavities.

COMPRESSION ADVANTAGES

  • Shorter cycle time and therefore higher productivity
  • Less energy consumption
  • High specific density
  • Fast and ordinary maintenance activities (not runners are missing)
  • Quick colour changeover
  • Less waste = lower costs

  • TECNICAL DATA CCM24SB CCM24SF
    Raw material PP - HDPE - LDPE - PS - PET - PC - BIO
    Outer max ø mm 41 41
    Max height mm 25 25
    Number of cavities 24 24
    Max prod.Capacity pcs/minute   600 1000
    Electrical power (up to) kw/kg 0,58 0,40
    Overall dimension mm 6400x2360 7600x2550
    Min cycle time s 2,4 1,44
    Smart Pack / Available

  • TECNICAL DATA   CCM32MC
    Raw material   PP - HDPE - LDPE - PS - PET - PC - BIO
    Outer max ø mm 53
    Max height mm 25
    Number of cavities   32
    Max prod.Capacity pcs/minute 1066
    Electrical power (up to) kw/kg 0,4
    Overall dimension mm 7800x2850
    Min cycle time s 1,8
    Smart Pack   Available

  • TECNICAL DATA   CCM48SD
    Raw material   PP - HDPE - LDPE - PS - PET - PC - BIO
    Outer max ø mm 41
    Max height mm 25
    Number of cavities   48
    Max prod.Capacity pcs/minute 2000
    Electrical power (up to) kw/kg 0,4
    Overall dimension mm 8000x2850
    Min cycle time s 1,44
    Smart Pack   Available

  • TECNICAL DATA   CCM64MC
    Raw material   PP - HDPE - LDPE - PS - PET - PC - BIO
    Outer max ø mm 53
    Max height mm 25
    Number of cavities   64
    Max prod.Capacity pcs/minute 1920
    Electrical power (up to) kw/kg 0,45
    Overall dimension mm 9000x3500
    Min cycle time s 2
    Smart Pack   Available

  • TECNICAL DATA   CCMM32A
    Raw material   PP - HDPE - LDPE - PS - PET - PC - BIO
    Outer max ø mm 60
    Max height mm 45
    Number of cavities   32
    Max prod.Capacity pcs/minute 800
    Electrical power (up to) kw/kg 0,8
    Overall dimension mm 8700x2850
    Min cycle time s 2,4
    Smart Pack   Available

TECHNICAL FEATURES CCM24SB CCM24SF CCM32MC CCM48SD CCM64MC CCMM32A
Raw material PP - HDPE - LDPE - PS - PET - PC - BIO PP - HDPE - LDPE - PS - PET - PC - BIO PP - HDPE - LDPE - PS - PET - PC - BIO PP - HDPE - LDPE - PS - PET - PC - BIO PP - HDPE - LDPE - PS - PET - PC - BIO PP - HDPE - LDPE - PS - PET - PC - BIO
Max Ø (mm) 41 41 53 41 53 60
Max height (mm) 25 25 25 25 25 45
Number of cavities 24 24 32 48 64 32
Max prod. capacity (pcs/minute) 600 1000 1066 2000 1920 800
Electrical power average (kW/Kg) 0.58 0.40 0.40 0.40 0.45 0.8
Overall dimension (mm) 6400x2360 7600x2550 7800x2850 8000x2850 9000x3500 8700x2850
Min cycle time (s) 2.4 1.44 1.8 1.44 2 2.4
Smart Pack / Available Available Available Available Available
